Assembling Note: Mount the Panel holder as shown in the figure so that the section
"B" engages with the Hook of the Tilt hook.
Fig. 3-79
(5) Release the four Hooks and remove the Inner media cover.
Fig. 3-80
“B”
Panel holder
Tilt hook
Hook
1a
1b
Hook
Hook
Hook
Hook
Inner media cover
