BRP ROTAX 916 i A Series Installation Manual

BRP-Rotax
INSTALLATION MANUAL
ELECTRICAL INTERFACES – 916 I TYPE C24
Fuel pump
connectors
916 i TYPE C 24
Interface Parameter
Min. Max. Nominal
Output Voltage (V)
12 V 14.5 V 13.8 V
Output Current (A)
Fuel pump assy. (both pumps):
@ 12 V = 9.1 A [+/- 2 A]
Single pump:
@ 12 V = 5 A [+ 2.5 A / - 0.5 A]
Cockpit Air-
frame side
Connector PIN Function
Type
X4 A
14 V (for EMS, Battery Backup) Output
B
14 V GND (for EMS, Battery Backup) Output
C 14 V (for Fuel Pump 2 / Aux.) Output
D
14 V GND (for Fuel Pump 2 / Aux) Output
MECHANICAL INTERFACES
Adapter for fuel
pressure
Standard banjo bolt can be replaced by an optional Sensor adapter for connectivity di-
rectly on the fuel inlet of the fuel pressure regulator. See SI-PAC–024.
Interface Parameter
Min. Max.
Tightening torque
23 Nm (17 ft. lb) 27 Nm (20 ft.lb)
Component mass (adapter with sensor)
-
80 g
Connection: M12 x 1.5
Effectivity: 916 i A / C24
Edition 0/Rev. 1
73–00–00
Page 7
December 01 2023
