MECHANICAL INTERFACES – 916 I TYPE C24
Fusebox and
Converter assy.
mounting points
916 i TYPE C 24
Figure 3.17: Fusebox –Connections and dimensions
24–00–00
Page 18
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
