BRP-Rotax
INSTALLATION MANUAL
m WARNING
Non-compliance can result in serious injuries or death!
At higher positioning of the oil tank, oil might leak through clearances at bearings back
into crankcase. Oil tank will be empty and all oil will be in the crankcase. If fitted too low
it might happen that the oil filter will be drained. In that case oil pressure will be too low
for the first seconds after starting the engine.
OIL HOSE REQUIREMENTS
Main oil pump
(Oil circuit,
engine)
At negative pressure of -500 mbar (-7.25 psi) and a oil temperature of 150 °C (302 °F) the
oil lines must not collapse.
A minimum inner diameter of at least 10 mm (0.39 in.) should be used.
NOTE
Obey the pressure requirements on interfaces as specified, see crankcase pres-
sure and vacuum measurement.
Effectivity: 916 i A / C24
Edition 0/Rev. 1
79–00–00
Page 7
December 01 2023
