BRP-Rotax
INSTALLATION MANUAL
ENGINE HANDLING
NOTICE
Do not use the fuel lines or the wiring harness for lifting the engine!
Attachment
points
The engine may only be lifted on the dedicated attachment points by using the GENUINE-
ROTAX®- engine lift set and a spreader bar with 350 mm (13.78 in) distance between lift-
ing points. Make sure that lifting device does not bend the attachment lugs by relevant
force distribution.
Figure 2.3: Attachment points
Effectivity: 916 i A / C24
Edition 0/Rev. 1
10–10–00
Page 9
December 01 2023
