BRP-Rotax
INSTALLATION MANUAL
INSTALLATION OVERVIEW – 916 I TYPE C24
916 i TYPE C 24
Figure 10.11: Harness Interface Connector A-Schematic
Part Function
1 Harness Interface Connector A
2
Warning Lamp A (-H1)
3
Warning Lamp A (LED) (-H1 V2)
4
Resistor 1.5 kΩ (-R6)
5
Resistor 1 kΩ (-R7)
6
Display CAN A
7
Maintenance CAN A
77–00–00
Page 16
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
