BRP ROTAX 916 i A Series - Mechanical Interfaces

BRP-Rotax
INSTALLATION MANUAL
MECHANICAL INTERFACES
Exhaust tail pipe
Figure 11.3: Exhaust position
Interface Parameter
Value
Exhaust elbow material
X15CrNiSi20-12
NOTE
The resonator can be rotated as desired, but the orientation can only be changed
before initial operation. Afterwards M5x12 screws must not be removed.
Effectivity: 916 i A / C24
Edition 0/Rev. 1
78–00–00
Page 5
December 01 2023
