BRP-Rotax
INSTALLATION MANUAL
INSTALLATION OVERVIEW – 916 I TYPE C24
916 i TYPE C24
Figure 9.17: Harness Interface Connector A-Schematic
Part Function
1 Harness Interface Connector A
2
Lane Select Switch A (-S4)
3
Fuel Pump Switch 1 (-S7)
76–00–00
Page 18
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
