BRP ROTAX 916 i A Series - Interface Description; Interface Overview

BRP-Rotax
INSTALLATION MANUAL
INTERFACE DESCRIPTION
INTERFACE OVERVIEW
Interface
overview
Figure 6.3: Air intake: Interface overview and components
1 Air filter connection 2
Connection turbocharger to intercooler
3
Connection intercooler to pop off valve
4
Air intake hose (pop off valve to throttle
body)
5
Turbocharger
6 Intercooler
7
Pop off valve
8
Throttle body
72–60–00
Page 6
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
