BRP-Rotax
INSTALLATION MANUAL
Vent socket
Interface Parameter
Value
Outside diameter 8 mm (0.31 in.)
Slip–on length 15 mm (0.59 in.)
m WARNING
In any case the vent fitting must ensure a release of pressure from the oil tank at
any time. Otherwise oil could emerge into the turbo housing which conveys
through the exhaust. Formation of smoke is possible.
Oil tank inlet (tur-
bo charger)
Interface Parameter
Value
Screw socket
M10x1
Tightening torque
15 Nm (133 in. lb)
OIL PUMP
Oil pump inlet The oil pump inlet must be connected directly with the oil tank outlet.
Interface Parameter
Value
Screw socket M22 x1.5 or 7/8–14 UNF
Tightening torque
25 Nm (18 ft. lb)
Oil return outlet The oil return outlet must be connected directly with the oil tank inlet.
Effectivity: 916 i A / C24
Edition 0/Rev. 1
79–00–00
Page 11
December 01 2023
