BRP ROTAX 916 i A Series - Page 196

BRP-Rotax
INSTALLATION MANUAL
NOTICE
Both oil return outlets need to be used. Only the oil return lines on magneto side
must be used. The hoses must have approx. the same length.
Figure 12.8: Oil return outlets
1 Oil return outlet
79–00–00
Page 12
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
