BRP ROTAX 916 i A Series Installation Manual

BRP-Rotax
INSTALLATION MANUAL
Interface Parameter
Value
Screw socket M18 x 1.5 or 3/4–16 UNF
Tightening torque
25 Nm (18 ft.lb)
Oil return outlet
(turbo charger)
The oil return outlet (turbo charger) must be connected directly with the oil tank inlet (turbo
charger).
Interface Parameter
Value
Screw socket M10 x 1
Tightening torque
15 Nm (133 in. lb)
Figure 12.9: Oil return outlet (turbo charger)
Effectivity: 916 i A / C24
Edition 0/Rev. 1
79–00–00
Page 13
December 01 2023
