BRP ROTAX 916 i A Series - Conversion Table

BRP-Rotax
INSTALLATION MANUAL
CONVERSION TABLE
Units of length: Units of power:
1 mm = 0.03937 in
1 in = 25.4 mm
1 ft = 12 in
= 0.3048 m
1 kW = 1.341 hp
1 hp = 0.7457 kW
1 kW = 1.3596 PS
1 PS = 0.7355 kW
Units of area: Units of temperature:
1 cm² = 0.155 sq. in (in²)
1 sq. in (in²) = 6.4516 cm²
K = °C – 273,15
°C = (°F – 32) / 1,8
°F = (°C x 1.8) +32
Units of volume: Units of velocity:
1 cm³ = 0.06102 cu in (in³)
1 cu in (in³) = 16.3871 cm³
1 dm³ = 1 l
1 dm³ = 0.21997 gal (UK)
1 gal (UK) = 4.5461 dm³
1 dm³ = 0.26417 gal (US)
1 gal (US) = 3.7854 dm³
1 m/s = 3.6 km/h
1 ft/min = 0.3048 m/min
= 0.00508 m/sec
1 m/s = 196.85 ft/min
1 kt = 1.852 km/h
1 km/h = 0.53996 kn
Units of mass: spec. fuel consumption:
1 kg = 2.2046 lbs.
1 lb. = 0.45359 kg
1 g/kWh = 0.001644 lb/hph
1 lb/hph = 608.277 g/kWh
Density:
Units of torque:
1 g/cm³ = 0.016018 lb/ft³
1 lb/ft³ = 62.43 g/cm³
1 Nm = 0.737 ft lb
= 8.848 in lb
1 ft lb = 1.356 Nm
1 in lb = 0.113 Nm
Units of force: Cable cross-section: Conversion table-
Wire Gauge: AWG-mm²
1 N = 0.224809 lbf
1 lbf = 4.4482 N
AWG —> mm²
4 —> 21
6 —> 13
8 —> 8.4
10 —> 5.3
12 —> 3.3
14 —> 2.1
16 —> 1.3
18 —>0.8
20—> 0.52
Units of pressure:
1 Pa = 1 N/m²
1 bar = 100 000 Pa / 1000 hPa / 100 kPa
1 bar = 14.503 lbf/in² (psi)
1 in Hg = 33.8638 hPa
00–00–00
Page 12
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
