INSTALLATION MANUAL
APPROVAL OF ELECTRIC AND ELECTRONIC COMPONENTS
(EQUIPMENT QUALIFICATION ACCORDING TO RTCA/DO-160)
RTCA/DO-160 defines a series of minimum standard environmental test conditions and
applicable test procedures for airborne equipment. The purpose of these tests is to pro-
vide a laboratory means of determining the performance characteristics of airborne equip-
ment in environmental conditions representative of those which may be encountered in
airborne operation of the equipment.
Electric and Electronic components (incl. wiring harness, ECU, Fuse Box, PMA, Sensors
and Actuators) of the 916 i A Series are considered as part of the equipment and have
been tested and qualified according to the following table:
DO-160G, Section 4 — Temperature and Altitude Cat. B3V
1
DO-160G, Section 5— Temperature Variation Cat. B
DO-160G, Section 6— Humidity Cat. B
DO-160G, Section 7— Operational Shocks and Crash Safety Cat. BD
DO-160G, Section 8 — Vibration Cat. S (L)
DO-160G, Section 9 — Explosion Proofness Test not performed
DO-160G, Section 10 — Water Proofness Cat. S
DO-160G, Section 11 — Fluids Susceptibility Cat. F
DO-160G, Section 12 — Sand and Dust Cat. D
DO-160G, Section 13 — Fungus Resistance Test not performed
DO-160G, Section 14 — Salt Spray Cat. S
DO-160G, Section 15 — Magnetic Effect Cat. A
DO-160G, Section 16 — Power Input Cat. BXX
DO-160G, Section 17 — Voltage Spike Cat. A
DO-160G, Section 18 — AF Cond. Susceptibility Cat. Z
DO-160G, Section 19 — Induced Signal Susceptibility Cat. ZCX
DO-160G, Section 20 — RF Susceptibility Conducted
DO-160G, Section 20 — RF Susceptibility Radiated
Cat. M
Cat. D
DO-160G, Section 21 — Emission RF Energy Conducted
DO-160G, Section 21 — Emission RF Energy Radiated
Cat. B
Cat. B
DO-160G, Section 22 — Lightning Induced Trans.
Suspectibility
Cat. B3H3L3
DO-160G, Section 23 — Lightning Direct Effects Test not performed
Effectivity: 916 i A / C24
Edition 0/Rev. 1
00–00–00
Page 19
December 01 2023
1. Components were tested at „operating low temperature“ of - 40 °C (- 40° F) instead of - 45 °C (- 49 ° F).
