BRP-Rotax
INSTALLATION MANUAL
means, but not the only acceptable means, of corrosion treatment. The information in this
AC is applicable to aircraft for which the manufacturer has not published corrosion control
information.
UNPACKING THE ENGINE
NOTICE
The attachment screws are only for transport and must not be used in the
aircraft.
NOTICE
During engine installation take into account the total engine weight and ensure
careful handling.
Unpacking the
engine
When the engine is delivered, check for damage of the packaging. If the package is dam-
aged, contact a ROTAX® Authorized Distributor or their independent Service Center for
ROTAX® aircraft engines.
To unpack a new engine and for checking the state of delivery, proceed as follows:
1. Remove the wooden cover.
2. Remove the bag and protective wrapping around the engine.
3. Check that the serial number and engine type on the type plate are identical to those shown
on the delivery note.
If the serial number or the engine type is deviating from the delivery contact a ROTAX® Au-
thorized Distributor- or their independent Service Center for ROTAX® aircraft engines.
4. Check the engine for damage or corrosion.
If the engine is damaged or corroded, contact a ROTAX® Authorized Distributor- or their in-
dependent Service Center for ROTAX® aircraft engines.
5. Screw off the transport bracket screws from wooden bottom of the box.
6. Remove transport brackets from engine.
Protective
coverings
NOTICE
Protective coverings are only for use during transport and engine installation.
They must be removed completely (including sealing materials) before the en-
gine is operated.
All openings are protected against ingress of contamination and dampness. It is recom-
mended to leave the protective plugs in place until installation of the specific feed line.
The protective coverings can be found at following locations:
Effectivity: 916 i A / C24
Edition 0/Rev. 1
10–10–00
Page 5
December 01 2023
