BRP ROTAX 916 i A Series Installation Manual

BRP-Rotax
INSTALLATION MANUAL
Pos. Installation location Amount
1 Muffler assy. with resonator assy.
2
Fuel rail 2/4 outlet line / fuel pressure regulator
3
Fuel rail 1/3 feed line
4
Oil inlet/outlet and turbo return line to tank
5
Coolant inlet/outlet
6 Throttle body socket assy.
7
Air intake socket on turbocharger
8 Connection to / from intercooler
9
Propeller shaft
10 Intercooler
11
Pressure Control Valve (PCV)
12 Governor flange
10–10–00
Page 6
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
