BRP-Rotax
INSTALLATION MANUAL
SYSTEM DESCRIPTION
The complete system is volume of supply and is certified together with the engine. For a
detailed system description refer to latest issue of the Operators Manual (OM).
SYSTEM LIMITATIONS
Maintenance CAN The Maintenance CAN must only be used in combination with a B.U.D.S. Aircraft USB-to-
CAN converter and B.U.D.S. Aircraft Software. It is not possible to use the Mainte-
nance CAN for other displaying or data logging purposes.
CAN wiring For the Display- and the Maintenance CAN twisted and shielded cables (3 pins: CAN_H,
CAN_L, CAN_GND) must be used for the CAN-connections to ensure a high electromag-
netic compatibility in data transmission.
77–00–00
Page 4
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
