BRP-Rotax
INSTALLATION MANUAL
SCOPE OF SUPPLY
Basic • 4- stroke-, 4 cylinder horizontally opposed-, spark ignition engine, single central cam-
shaft push rods —OHV (Over Head Valve)
• Liquid cooled cylinder heads
• Ram air cooled cylinders
• Dry sump forced lubrication
• Fully redundant electronic engine management system (EMS) for controlling fuel injec-
tion, ignition, etc.
• Propeller drive via gearbox with integrated torsional vibration absorber and overload
clutch
• Oil tank
• Electric starter
• Turbocharger
• Electronic/pneumatic control of boost pressure
• Exhaust system
Optional • Accessory drive for hydraulic propeller governor (configuration 3 only)
• Cooling air baffle
00–00–00
Page 4
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
