BRP ROTAX 916 i A Series Installation Manual

BRP-Rotax
INSTALLATION MANUAL
Figure 6.2: Figure shows idle position
1 Bowden cable 2
Spring-loaded screw (idle speed
adjustment)
3
Screw with black cap (maximum setting
for lowest idle speed)
4
Locking varnish
m WARNING
Non-compliance can result in serious injuries or death!
With throttle lever not connected the throttle valve will remain fully open. The starting
position of the throttle valve is therefore full throttle! Therefore never start the engine
without connecting the throttle lever first.
m WARNING
Non-compliance can result in serious injuries or death!
The cable actuations being used must not be affected at all by vibrations emanating
from the engine or the airframe.
Effectivity: 916 i A / C24
Edition 0/Rev. 1
72–60–00
Page 5
December 01 2023
