BRP ROTAX 916 i A Series Installation Manual

BRP-Rotax
INSTALLATION MANUAL
Throttle lever Adjust Bowden cable such that throttle valve can be fully opened and closed.
Step
Procedure
1
Push to “full throttle”, then adjust Bowden cable so that it has 1 mm (0.04
in.) clearance (no tensioning), thereby ensured that throttle valve is com-
pletely open.
NOTE
Spring pulls the throttle valve to full throttle position.
2 Push to "idle". Set the spring-loaded screw that the throttle lever hits the
stop screw with the black cap (maximum setting for lowest idle).
3
If the idling speed is too low, then open throttle lever with the spring-loaded
screw until the required idling speed is reached
4 Mark adjustments with locking varnish.
NOTE
It is not recommended to install a throttle limiter. With the installation of a throttle
limiter, the engine can not reach its nominal power.
72–60–00
Page 4
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
