BRP ROTAX 916 i A Series Installation Manual

BRP-Rotax
INSTALLATION MANUAL
Generator B
(stator cable
from ignition
housing)
Connector PIN Function
Type
X1 A
Phase 1 of Generator
Input
B
Phase 2 of Generator
Input
C Phase 3 of Generator
Input
Aircraft 28 V
Bus / Battery
24 V
Connector PIN Function
Type
X2 A
28 V (output for Aircraft) Output
B
28 V GND (output for Aircraft) Output
C +24 V (Aircraft Battery Plus Pol)
Input
Generator B (
connector
from
Fusebox)
Connector PIN Function
Type
X3 A
14 V (for EMS, connected at Fusebox B Minus
Pol)
Output
B
14 V GND (for EMS, connected at Fusebox B
Minus Pol)
Output
Cockpit Air-
frame side
Connector PIN Function
Type
X4 A
14 V (for EMS, Battery Backup) Output
B
14 V GND (for EMS, Battery Backup) Output
C 14 V (for Fuel Pump 2 / Aux.) Output
D
14 V GND (for Fuel Pump 2 / Aux) Output
X5
See Chapter 77-00-00.
Effectivity: 916 i A / C24
Edition 0/Rev. 1
24–00–00
Page 17
December 01 2023
