INSTALLATION MANUAL
Interface Parameter
Value
Pitch circle diameter 80
mm (3.15 in.)
6x through holes 13 mm (0.51 in.)
Pitch circle diameter 101.6
mm (4 in.)
6x through holes 13 mm (0.51 in.)
Hub diameter
47 mm (1.85 in.)
Gear transmission i=2.54. Propeller shaft turns with 0.395 times engine
speed.
Figure 4.6: Direction of rotation
Effectivity: 916 i A / C24
Edition 0/Rev. 1
61–00–00
Page 7
December 01 2023
