2007 Buell Lightning: Engine 3-11
HOME
15. Remove left side rider footrest and support plate .
16. See Figure 3-4. Disconnect clutch cable.
a. Remove wire form (1) from front isolator.
b. Slide clutch cable adjuster boot (2) up to access
clutch adjuster.
c. Loosen clutch adjuster to release tension from hand
lever.
d. Remove clutch cable ferrule from hand lever.
Figure 3-4. Clutch Cable Wire Form and
Adjuster Boot
1. Wire form
2. Clutch cable adjuster boot
1
2
10502
