Buell 2007 LIGHTNING Service Manual

4-122 2007 Buell Lightning: Fuel System
HOME
Testing
1. Remove intake cover assembly. See 2.38 INTAKE
COVER ASSEMBLY.
2. Remove air cleaner cover. See 4.44 AIR CLEANER
ASSEMBLY.
3. Conduct test.
a. Turn key ON for two seconds.
b. Turn key OFF for two seconds.
c. Repeat Steps A and B five consecutive times.
d. Open throttle, replace fuel injectors if there is any
evidence of raw fuel in throttle body manifold.
4. Install air cleaner cover. See 4.44 AIR CLEANER
ASSEMBLY.
5. Install intake cover assembly. See 2.38 INTAKE COVER
ASSEMBLY.
Figure 4-113. Fuel Injectors
2
5
1
1. Fuel rail fastener
2. Rear fuel injector
3. Fuel rail assembly
4. Clip (2)
5. Front fuel injector
10644
3
4

Buell 2007 LIGHTNING Specifications

General

Year	2007
Manufacturer	Buell
Model	Lightning
Category	Motorcycle
Displacement	1203 cc
Bore x Stroke	88.9 mm x 96.8 mm
Compression Ratio	10.0:1
Fuel System	Electronic fuel injection
Transmission	5-speed
Final Drive	Belt
Rear Suspension	Showa shock absorber
Rear Brakes	Single disc, 1-piston caliper
Engine Type	V-Twin
Ignition	Digital
Front Suspension	Showa inverted fork
Front Brakes	Single disc, 6-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	52.0 inches
Seat Height	30.1 inches
Dry Weight	395 lbs
Fuel Capacity	14.5 liters
