5-16 2007 Buell Lightning: Starter
HOME
Figure 5-17. Undercutting Mica Separators
Mica must not be left with a
thin edge next to segments
RIGHT WAY
Mica
Undercutting mica with
piece of hacksaw blade
WRONG
WAY
Starting groove in mica
with 3 cornered file
Mica must be cut away
clean between segments
b0136x5x
Mica
Segments
Segments
