Buell 2007 LIGHTNING Service Manual

6-44 2007 Buell Lightning: Drive/Transmission
HOME
6. See Figure 6-82. Thread NUT (Part No. HD-47856-5)
onto end of adapter, until it tightens against installer.
7. See Figure 6-83. Place CROWFOOT WRENCH (Part
No. HD-47856-7) (1) with 1/2 inch drive breaker bar (2)
on large nut. Place an adjustable wrench (3) on flats of
hex head cast into end of adapter.
8. Holding smaller wrench, tighten nut with larger wrench
until outer face of seal is flush with outer edge of crank-
case bore.
NOTE
It is acceptable to recess seal to about 0.030 in. (0.762 mm)
below outer edge of bore. Seal will be controlled by tool.
9. Remove nut, installer, adapter and pilot.
Figure 6-82. Install NUT (Part No. HD-47856-5) (Typical)
12044
Figure 6-83. Press Seal Into Crankcase
12089
1
3
2
1. CROWFOOT WRENCH
2. 1/2 inch breaker bar
3. Adjustable wrench

Buell 2007 LIGHTNING Specifications

General

Year	2007
Manufacturer	Buell
Model	Lightning
Category	Motorcycle
Displacement	1203 cc
Bore x Stroke	88.9 mm x 96.8 mm
Compression Ratio	10.0:1
Fuel System	Electronic fuel injection
Transmission	5-speed
Final Drive	Belt
Rear Suspension	Showa shock absorber
Rear Brakes	Single disc, 1-piston caliper
Engine Type	V-Twin
Ignition	Digital
Front Suspension	Showa inverted fork
Front Brakes	Single disc, 6-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	52.0 inches
Seat Height	30.1 inches
Dry Weight	395 lbs
Fuel Capacity	14.5 liters
