2007 Buell Lightning: Electrical 7-7
HOME
7. See Figure 7-4. Use Snap-on Tamper-Resistant T45 Torx
driver (Part No. FTXR45E) to remove the two tamper-
resistant Torx fasteners (2) securing ignition switch to
upper fork clamp.
8. Remove the final ignition switch fastener (1) along with
spacer located behind the ignition switch.
9. While holding the throttle cables (3) to your left (the right
side of the vehicle), pull the ignition switch (4) toward you
and roll the assembly away from you until the fork stop
pin (5) is pointing down.
10. Slide the ignition switch assembly out to your left (the
right side of the vehicle).
Figure 7-4. Ignition Switch (Typical)
1. Socket head fastener (1), with spacer behind switch
2. Tamper-resistant Torx fasteners (2)
3. Throttle cables
4. Ignition switch as positioned on vehicle
5. Fork stop pin (retracted)
2
4
5
1
3
8899
8904
8902

Buell 2007 LIGHTNING Specifications

General

Year	2007
Manufacturer	Buell
Model	Lightning
Category	Motorcycle
Displacement	1203 cc
Bore x Stroke	88.9 mm x 96.8 mm
Compression Ratio	10.0:1
Fuel System	Electronic fuel injection
Transmission	5-speed
Final Drive	Belt
Rear Suspension	Showa shock absorber
Rear Brakes	Single disc, 1-piston caliper
Engine Type	V-Twin
Ignition	Digital
Front Suspension	Showa inverted fork
Front Brakes	Single disc, 6-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Wheelbase	52.0 inches
Seat Height	30.1 inches
Dry Weight	395 lbs
Fuel Capacity	14.5 liters
