Starter Test (Part 2 of 2)
CONDITION: Key ON, transmission in gear and clutch disengaged
YES
Check for ground on
TN/LTGN wire of clutch
switch connector [95].
Ground present?
YES
Repair open on TN/
LTGN wire between
connector [95] and
starter relay.
NO
Replace clutch
switch.
Check for ground on BK
wire of connector [95].
Ground present?
NO
Repair open on
BK wire between
connector [95] and
ground.
5073
5074
5075
YES
Depress starter button.
Does Starter work?
NO
System OK
