3-10 2007 Buell P3: Engine
HOME
15. See Figure 3-6. Loosen hose clamp.
16. See Figure 3-7. Remove crankcase breather hose.
17. See Figure 3-8. Disconnect auto-enrichener plug.
18. Place air cleaner and carburetor as an assembly on top
of frame.
NOTES
●
For more details about the air cleaner see 4.3 AIR
CLEANER.
●
The steps mentioned previously complete disassembly
preparation for top end servicing. You may now proceed
with TOP END DISASSEMLY PROCEDURES. See 3.5
CYLINDER HEAD.
●
If continuing engine removal proceed to step 20.
NOTE
The remaining steps are required to complete engine
removal.
19. Place jack under the motor. Use jack to lower motor.
20. Move jack forward.
21. Place wooden cradle under engine.
Figure 3-6. Hose Clamp
Figure 3-7. Crankcase Breather Hose
7648
7649
1
2
1. Breather hose
2. Three-way connector
Figure 3-8. Auto-Enrichener Plug
1. Auto-enrichener plug
2. Frame
2
1
7631
