3-12 2007 Buell P3: Engine
HOME
Table 3-19. Electrical Items Disconnected for Engine Disassembly
DESCRIPTION LOCATION
Ignition module [10] Located on frame backbone.
Speedo sensor [65] Located under seat (right side-tucked in under cavity).
Sidestand switch [60] Tie wrapped to rear brake line.
Neutral switch [131] Disconnect at neutral switch.
Oil pressure switch [120] Disconnect at oil pressure switch.
Alternator stator [46] Located under seat (left side).
Starter solenoid wire [128] Disconnect at starter.
Spark plug wire Located on spark plug.
Battery—positive wire Disconnect at main circuit breaker.
Rear brake light switch [121] Located under frame by shock absorber.
