NOTE:
Most Campbell Scientific devices come from the factory with a default PakBus address of 1.
For this reason, it is best not to assign PakBus address 1 to any device in the network. Then, if
a new device with default settings is added to the system, it will not create a conflict.
1. Ensure the antenna is connected.
2. For data loggers with an external radio, connect the radio and data logger CS I/O ports
using an SC12 cable.
3. Supply 12 VDC power to the data logger.
l
connect 12VDC at the green BAT terminals
l
or connect 16 to 32VDC at the CHG terminals
13. Radio communications option57
