Model 190 Installation, Technical and Operation
8400-M022-O1 Rev J
1.1 Standard Features
Push button tare function
Gross, tare, net conversion
Selectable key lockout
Hi-Resolution mode
StableSENSE
® 1
adjustable digital filtering
Gross and Net accumulators
Single serial port
Remote input line for Zero, Tare, Gross and Print (1000
feet maximum)
Programmable print format using Visual Print or nControl
(1 Visual Ticket available)
SMA level 2 compliant serial communications (For more
information see http://www.scalemanufacturers.org)
Field re-programmable via PC interconnection
Test feature (performs display and internal tests)
Auto Shutoff and Sleep modes
Battery operation (Requires additional hardware and
includes additional documentation)
1.2 Optional Features
Additional Serial Port (190-RS232)*, Ethernet TCP/IP (190-IP) *,
WiFi Wireless Ethernet TCP/IP (190-WIFI) *, Analog Output
(190-DAC) * Special Filtering, and Column Mounting
*This feature requires additional hardware.
1
StableSENSE
®
is a digital filter utilizing proprietary software
algorithms to remove or greatly reduce changes in the weight
display resulting from movement on the scale platform.
StableSENSE
®
can be used with livestock and single animal
scales to lessen the effects of the animal’s movement on the
scale or it can be used with vehicle scales to lessen the effects of
wind and vehicle vibration. Any application affected by vibration
or movement on the scale platform can benefit using
StableSENSE
®
.
