Model 190 Installation, Technical and Operation
8400-M022-O1 Rev J
4.10 Fine Span Adjustment
IMPORTANT! The FSPAn (FSPAn?) mode requires a
load of 10% of Capacity on the scale before adjustments
can be made.
F span
Fine Span Adjustment (from SETUP Prompt)
1. If Fine Span Adjustment is desired, with the SETUP prompt
displayed, press the UNITS/ key until the display shows the
FSPAn prompt.
2. Place a calibrated test weight on the scale and press the TARE key.
3. The display will change to show the amount of the test weight, an F
will be displayed to the right of the annunciators and the
annunciators will alternately flash off and on.
4. Press the Fn/ key to increase the span by 0.5 division OR press
the UNITS/ key to decrease the span by 0.5 division.
5. Press the TARE key to exit the Fine Span Adjustment and
advance to the Hires? prompt.
Fspan?
Fine Span Adjustment (after pressing TARE at last Print prompt)
1. With fspan? displayed, press the TARE key.
2. The display will change to no.
3. Place a calibrated test weight on the scale.
4. Press the Fn/ key to toggle to yes and then press the TARE key.
5. The display will change to show the amount of the test weight, an F will
be displayed to the right of the annunciators and the annunciators will
alternately flash off and on.
6. Press the Fn/ key to increase the span by 0.5 division OR press the
UNITS/ key to decrease the span by 0.5 division.
7. Press the TARE key to exit the Fine Span Adjustment and advance
to the Hires? prompt.
