Model 190 Installation, Technical and Operation
8400-M022-O1 Rev J
4.5 Analog to Digital Filtering
A-d
With A-d displayed, press the TARE key. The display will change to
dFLt=. Proceed to the dFLt= parameter.
A-d?
With A-d? displayed, press the TARE key. The display will change
to no. Press the Fn/ key to toggle to yes and then press the
TARE key. The display will change to dFLt=. Proceed to the
dFLt= parameter. Otherwise, to skip the Analog to Digital Filtering
setup, press the TARE key to advance to the CAL?. prompt.
dFLt= (Digital Filtering)
With dFLt= displayed, press the TARE key to show the current setting.
If the setting displayed is acceptable, press the TARE key to save it.
Otherwise, use the Fn/ key to toggle to a new setting and then press the
TARE key to save it. Allowable settings are: 0, 1, 2 or 3. Note, that if
you select 3 (Custom Filtering) two additional prompts will be displayed.
Filter Level = 2, Break Range = 1
Filter Level = 6, Break Range = 12, Sample Rate = 2
Filter Level = 20, Break Range = 12, Sample Rate = 1
NOTE: The prompts, F= (Filter Level) and b= (Break Range) will only be
displayed if you selected 3 (Custom Filtering) for the dFLt= (Digital
Filtering) prompt.
Digital Filtering (dFLt=) selections 0, 1 and 2 have fixed factory settings
for Filter Level, Break Range and Sample Rate.
