Cardinal 190 Series User Manual

Model 190 Installation, Technical and Operation
8400-M022-O1 Rev J
Page 169
18. APPENDIX F – 190-DAC OPTION
The 190-DAC is an option card for the 190 that outputs an analog 0-10V
or 0-24mA. The user can control the output voltage or current using the
DAC interface in the 190. The DAC has sense jumpers that allow the user
to connect the 190-DAC card voltage or current lines long distances.
If the Voltage or Current lines need to go long distances the user will need
to connect the polarized sense lines as close to the other end connections
as possible and remove sense jumpers J1 (+SEN) and J2 (-SEN). Refer
to Section 18.3 DAC Wiring for the location of J1 and J2. If the sense
lines are not needed the jumpers need to be installed.
NOTE: NOTE: The 190-DAC Option cannot be added in the
field. It requires returning the 190 to the factory to perform the
upgrade.
18.1 Specifications
Temperature Range:
14 to 104 F (-10 to +40 C)
Maximum Load Resistance:
0 – 20 mA and 4 – 20 mA
0 – 24 mA
500 ohms
450 ohms
Minimum load resistance:
2K ohms
Internal Connection:
10-pin DIL
+9V Internal Connection:
Connect to P2 of 190 Main Board
Pin +9V and GND
(Refer to Section 18.3 DAC Wiring)
9VDC ± 5%
External Connection:
5 terminal pluggable connector
Output Isolation:
1kV
