Model 190 Installation, Technical and Operation
8400-M022-O1 Rev J
4.11 Display High Resolution Weight
IMPORTANT! The Hires (Hires?) mode requires a load of
10% of Capacity on the scale.
Hi res
High Resolution Weight (from SETUP Prompt)
1. If displaying High Resolution Weight is desired, with the SETUP
prompt displayed, press UNITS/ key until the display shows the
Hires prompt.
2. Place a calibrated test weight on the scale and press the TARE key.
3. The display will change to show the amount of the test weight in
"high resolution" mode (1/10 division), an h will be displayed to the
right of the annunciators and the annunciators will alternately flash
off and on.
4. Press the Fn/ key to increase the span by 0.1 division OR press
the UNITS/ key to decrease the span by 0.1 division.
5. Press the TARE key to exit the Display High Resolution Weight
and advance to LoCoUt? prompt.
Hires?
High Resolution Weight (after TARE pressed at FSPAN prompt)
1. With Hires? displayed, press the TARE key.
2. The display will change to no.
3. Place a calibrated test weight on the scale.
4. Press the Fn/ key to toggle to yes and then press the TARE key.
5. The display will change to show the amount of the test weight in "high
resolution" mode (1/10 division), an h will be displayed to the right of
the annunciators and the annunciators will alternately flash off and on.
6. Press the Fn/ key to increase the span by 0.1 division OR press the
UNITS/ key to decrease the span by 0.1 division.
7. Press the TARE key to exit the Display High Resolution Weight and
advance to the LoCoUt? prompt.
