Model 190 Installation, Technical and Operation
8400-M022-O1 Rev J
dACtSt
Press the TARE key and then the Fn/▲ key to switch to the YES
prompt. Press the TARE key to enter the DAC output test function,
pressing the TARE key with the no prompt will skip the output test.
The dAC Lo prompt is displayed and the output of the DAC is the Low
value for the range selected. Press the Fn/▲ key to switch to the High
value of the range on the DAC output, dAC Hi will be displayed.
Continue pressing the Fn/▲ key to toggle between the Low and High
output. When done testing the DAC output press the TARE key.
9dAC=
This sets the DAC output to follow the Gross weight only or the displayed
weight (gross or net).
Press the TARE key to show the current value. If the setting displayed
is acceptable, press the TARE key again to save it and advance to the
fUnC? prompt.
Otherwise, press the Fn/▲ key to toggle between YES and no and then
press the TARE key and advance to the fUnC? prompt.
DAC output is Gross Weight
Only
DAC output is the displayed
Weight (gross or net)
18.4 DAC Wiring
DAC Option Card P1 Power Connection
To power the DAC option card, connect P1 on the DAC (Pin +9V and
GND) to connector P2 of 190 Main Board (Pin +9V and GND).
DAC Option Card P3 Analog Out Connections
To Next Page
