Model 190 Installation, Technical and Operation
8400-M022-O1 Rev J
13. APPENDIX A – BP190 Optional Battery Pack
13.1 BP190 Contents:
CABLE TIE LARGE 8" SST2SM
BATTERY PACK LI-ION 7.2V, 2600 mAH 6”
LEADS
13.2 BP190 Specifications:
DISCHARGE CURRENTS
Current ~ Continuous Operation
Ambient temp will change this quite a bit
CHARGING
To recharge the battery pack, the AC power adapter must be connected to
an AC power outlet and plugged into the indicator. It will take
approximately six (6) hours to fully recharge the battery pack in the
indicator. While the battery pack is charging the indicator can still be
operated. NOTE: Charging the battery pack for more than six (6) hours
will not damage it.
CHARGING GUIDELINES
DO NOT charge battery below freezing.
DO NOT charge battery above 40 C.
Lithium-ion does not need to be fully charged; a partial charge is
acceptable.
Battery does not need to be fully discharge between charging cycles.
