1-GENERALINFORMATION

Productidentication

Model,ProductIdenticationNumber(PIN),andyearofmanufacture

RecordthemachineProductIdenticationNumber(PIN)andadditionalmachineinformationincludingthemodeland

thecomponentserialnumbersinthespacesbelow.Alwayssupplythisinformationtoyourdealerwhenyouorder

parts,obtaininformation,orrequireassistance.KeeparecordofthesenumbersandyourManufacturer’sStatement

ofOrigininasafeplace.Ifthemachineisstolen,reportthenumberstoyourlocallawenforcementagency.

Machineidentication

Modelname

ProductIdenticationNumber(PIN)

Modelyear

ThePINplateislocatedontheleft-handsideofthema-

chineinfrontoftheengineaccessdoor.

RAIL13DOZ1610AA1

Roll-OverProtectiveStructure(ROPS)

TheROPSserialnumberplateislocatedintheleft-hand

rearaccesscompartment.

RAIL15DOZ0015AA2

Enginemakeandmodel

Engineserialnumber

Theserialnumberplateisontheenginevalvecover.

RAIL12DOZ0401AA3

1-5
