CASE CONSTRUCTION 1150M - Final Drive Oil

7-MAINTENANCE
Finaldriveoil
CAUTION
Burnhazard!
Waitforallcomponentstocoolbeforeperforminganyoperation.
Failuretocomplycouldresultinminorormoderateinjury.
C0053A
WARNING
Chemicalhazard!
Whenhandlingfuel,lubricants,andotherservicechemicals,followthemanufacturer'sinstructions.
WearPersonalProtectiveEquipment(PPE)asinstructed.Donotsmokeoruseopename.Collect
uidsinpropercontainers.Obeyalllocalandenvironmentalregulationswhendisposingofchemi-
cals.
Failuretocomplycouldresultindeathorseriousinjury.
W0371A
Changetheoilinthenaldriveandtheplanetarydrivewhenthehourmeterregisters1000hours.Changetheoil
every1000hoursthereafterormoreoftenifconditionssorequire.
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake
applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-
ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning
maintenance.Themachineshouldbeparkedtomakethedrainscorrectlyaccessible(seetheillustrations).
Servicespecications
TypeofoilCASEAKCELAGEAR135HEP85W-140
Capacity(eachside)14.2l(15USqt)
1.Cleantheareaaroundthenaldrivell/checkanddrain
plugs.Thedrainplugsarelocatedunderthehousing.
2.Cleantheareaaroundtheplanetarydriveplugs.
RAIL13DOZ1269AA1
NOTE:Thenaldriveandplanetarysharethesameoil.Completethedrainingprocessforboththenaldriveand
planetarysimultaneously.
3.Removethenaldrivell/checkplug(1)slowly.
7-70
