CASE CONSTRUCTION 1150M - Foot Controls

3-CONTROLSANDINSTRUMENTS
Footcontrols
Dualfunctionpedal
Thedualfunctionpedalcanbeswitchedtooperateasadecelerationpedaloratransmissioncontrolpedal.Asa
decelerationpedal,theengineRPMisreducedasthepedalisdepressed.Asatransmissionpedal,thehydraulic
systemisde-strokedasthepedalisdepressed.Thetransmissionpedalisthedefaultfunction.Thesesettingsare
madethroughthetransmissionselectiononthemulti-functiondisplay.
NOTE:Seethemulti-functiondisplayonpage4-14for
moreinformation.
Transmissionpedal
Asatransmissionpedal,themachinevariesthetransmis-
sionow(pump/motordisplacement)allowingforinching.
Pushingthepedalcompletelydownwillde-strokethehy-
draulics.
RAIL13DOZ1616AA1
Decelerationpedal
ThedecelerationpedalreducestheengineRPMand
slowsthemachine.Pushthedecelerationpedaltoslow
orstopthemachine.
RAIL12DOZ1254AA2
Usethedecelerationpedaltoreducethespeedallthe
waytozerobyde-strokingthegrounddrivealongwith
decreasingtheengineRPM.
NOTE:Usethedecelerationpedaltocontrolthedozerfor
precisionwork.
474495663
3-9
