3-CONTROLSANDINSTRUMENTS

Rippercontrollever

Movetherippercontrolleverforwardrighttothe(1)posi-

tiontolowertheripper.

Movetherippercontrollevertothebackleft(2)position

toraisetheripper.

Theripperwillstopmovingwhenthecontrolleverisin

theHOLDposition.Whenreleased,thecontrolleverwill

returntotheHOLDpositionautomatically.

RAPH12DOZ0081AA1

Awinchcanalsobeusedwiththiscontrol.Selectwinchor

ripperfromthemulti-functiondisplayconguration.Only

useanapprovedwinch.

3-35
