CASE CONSTRUCTION 1150M - Battery Removal and Installation

7-MAINTENANCE
Batteryremovalandinstallation
CAUTION
Heavyparts!
Machinebatteriesareextremelyheavy.Makesurethebatteryissupportedsafelyduringtheremoval
process.
Failuretocomplycouldresultinminorormoderateinjury.
C0050A
WARNING
Chemicalhazard!
Whenliftingaplastic-casedbattery,excessivepressureontheendwallscouldcauseacidtospill
throughtheventcaps.Liftaplastic-casedbatterywithabatterycarrierorwithyourhandspositioned
onoppositecornersofthebattery.Alwayswashyourhandsafterhandling.
Failuretocomplycouldresultindeathorseriousinjury.
W0385A
Prioroperation:
Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake
applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-
ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning
maintenance.
Replacingthebattery
1.TurntheelectronicdisconnectswitchtotheOFFposi-
tion.
RAPH12DOZ0121AA1
2.Removetheterminalprotectioncaps(1)fromthebat-
teries.
RAIL12DOZ0174AA2
7-115
