5-TRANSPORTOPERATIONS
Movingadisabledmachine
WARNING
Misusehazard!
Towingisadelicatemaneuverthatisalwayscarriedoutattheriskoftheuser.Themanufacturer's
warrantydoesnotapplytoincidentsoraccidentsthatoccurduringtowing.Wherepossible,carryout
therepairsatthesite.
Failuretocomplycouldresultindeathorseriousinjury.
W0286A
WARNING
Transporthazard!
MakesurethattheweightofatrailedvehiclethatisnotequippedwithbrakesNEVEREXCEEDSthe
weightofthemachinethatistowingthevehicle.Stoppingdistanceincreaseswithincreasingspeed
astheweightofthetowedloadincreases,especiallyonhillsandslopes.
Failuretocomplycouldresultindeathorseriousinjury.
W1138A
NOTICE:Thetowoptionbypasseshigh-pressurereliefvalves.Catastrophichydrostaticmotordamagecanoccurif
thehydrauliccircuitemptiesoroverheats.
Ifyourmachineisdisabled,youmustmakeajudgmentifthemachinecanbemovedwithoutmoredamage.Ifpos-
sible,repairthemachineatthejobsite.
Ifyoucannotrepairthemachineatthejoblocation,andifyouhaveatransporttrailer,parkthetrailerascloseas
possibletothemachine.Usearigidtowbartotowthemachine.
Keepallunauthorizedpersonnelclearofthearea.
Makecertainthatthemachineusedformovingthedisabledmachinehasthebrakingcapacity,weight,andpowerto
controlbothmachines.
Thetowingmachinemustbeequippedwitharearshieldtoprotecttheoperatorifthecableortowbardisengages.
Donotusechainstotowthismachine.
Ifnecessary,youcanattachasecondmachinebehindthedisabledmachinetoassistwithadditionalcontrolorbrak-
ing.
Youmustopenthepressurerelievevalvesinordertobypassthehydrostaticpumps.Therearetwouppervalvesfor
forwardmovementandtwolowervalvesforrearwardmovement.
NOTE:Youmustremovetheoormat,theoorpanel,andtiltthebackoftheoperator’sseatinordertoperformthis
procedure.
5-5
