7-MAINTENANCE

Driveshaftslipspline

Greasethedriveshaftslipsplineevery1000hoursofoperation.Removethecaboortoaccessthiscomponent.

Prioroperation:

Keepallunauthorizedpersonnelclearofthearea.Parkthemachineonlevelground,inneutralwiththeparkingbrake

applied,andtheattachmentloweredtotheground,turnofftheengine,removethekey,andverifythatenginecom-

ponentshavecooledoravoidcontact.Makesurethatallresidualpressureisrelievedfromcircuitsbeforebeginning

maintenance.

SpecicationTUTELAMOLYGREASEGR-75

Applygreaseatdriveshaftslipsplinetting.

NOTE:Universaljointsdonotrequirelubrication.

RAIL12DOZ1030AA1

7-74
