CASE CONSTRUCTION 1150M - Hydrostatic Drive Speed Controls

4-OPERATINGINSTRUCTIONS
Hydrostaticdrivespeedcontrols
WARNING
Hazardtobystanders!
Alwayssoundthehornbeforestartingthemachine.Makesuretheworkareaisclearofotherpersons,
domesticanimals,tools,etc.beforeyouoperatethemachine.Neverallowanyoneintheworkarea
duringmachineoperation.
Failuretocomplycouldresultindeathorseriousinjury.
W0304A
Thecrawlerhasvariablespeedselectionsineitherfor-
wardandreverse.Selectamaximumspeedinarange
of15increments.PresstheUP(1)orDOWN(2)button
tomovefromonespeedtoanother.Thisallowstheop-
eratortoincreasespeedoneincrementatatimebyeach
touchofthebutton.Movecontinuouslythroughthedrive
speedsbyholdingthebuttonin.
NOTE:Thespeedcanonlybeincreasedtothemaximum
drivespeedsetting.Themaximumdrivespeedsetting
canbeadjusted.Thehighestspeedfromthefactoryis
presetat15.
NOTE:Thetransmissionspeedwilldefaultto8whenthe
crawlerengineisshutoff.
NOTE:Thehornbuttonisalsolocatedonthejoystick.
Alwayssoundthehornbeforestartingthemachine.
RAPH12DOZ0079AA1
1.Hydrostaticdriveincreasespeed(Hare)
2.Hydrostaticdrivedecreasespeed(T ortoise)
Thedrivespeedonthemulti-functiondisplayshows
thespeedselected.Whenthecrawlerengineisinitially
turnedon,thedrivespeedwilldefaultto8.
Themulti-functiondisplayalsoshowsthepositionofthe
directioncontrolleverasForward(F),Neutral(N),orRe-
verse(R).IftheForRashes,thedirectionalcontrollever
mustbereturnedtoneutralbeforethecrawlerwillmove.
NOTE:Thecrawlerwillnotmoveunlesstheengineis
aboveapproximately1200RPM.
RAIL12DOZ0224AA2
