5-TRANSPORTOPERATIONS

Transportdimensions

Transportlengthandwidthwithbladefullyangledat25°

RAIL14DOZ0569FA1

Bladewidth

Transportwidth

Transportlength

withoutdrawbar

2489mm(120in)

2773mm(109.2in)5420mm(213.4in)

2642mm(132in)

3050mm(120.1in)5483.7mm(215.9in)

NOTE:Add240mm(9.4in)forunitequippedwithadrawbar.Add1188mm(46.8in)forunitequippedwitharipper.

5-13
