CASE CONSTRUCTION 1150M - Lifting the Machine and Transport Dimensions

5-TRANSPORTOPERATIONS
PREPARINGFORROADTRANSPORT
Liftingthemachine
WARNING
Crushinghazard!
Alwaysremovetheattachmentbeforeliftingthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W1195A
DANGER
Avoidinjury!
Themachinecantiltforwardorbackward.Leavetheliftingstrapsattachedinordertosecurethe
machine.
Failuretocomplywillresultindeathorseriousinjury.
D0110A
WARNING
Crushinghazard!
Theliftingsystemsmustbeoperatedbyqualiedpersonnelwhoareawareofthecorrectprocedures
tofollow.Makesureallliftingequipmentisingoodcondition,andallhooksareequippedwithsafety
latches.
Failuretocomplycouldresultindeathorseriousinjury.
W0256A
Liftinghooks
Liftthemachineusingthelifting
attachmentpointsidentiedonthe
machinebythelifthooksymbol.
NOTE:SeetheLiftSafetySignslocatedoneachsideof
themachine.
1.Keepallunauthorizedpersonnelclearofthearea.Do
notallowanyoneonthemachinewhileitisbeinglifted.
2.Removeanylooseitems,tools,etc.andlockalldoors.
3.Useliftingequipmentofsufcientweightliftingcapac-
ityforthismachine.Shieldthemachinewithclothor
padstoprotectnish.
4.Positionthemachinesothecenterofgravitybalances
themachine.
5.Liftthemachineslightly,andallowittobalanceand
stabilizebeforecontinuinglift.
RAPH12DOZ0062AA1
5-12
