3-CONTROLSANDINSTRUMENTS

EXTERIORCONTROLS

Masterdisconnectswitch

Themasterelectricaldisconnectswitchislocatedonthe

leftsideofthemachine.Theswitchhastwopositions:

ONandOFF.

MasterelectricalswitchON

ThemasterdisconnectswitchintheON

positionenergizestheentireelectrical

system.

MasterelectricalswitchOFF

AllmachinepowerisinterruptedintheOFF

position.

RAPH12DOZ0044AA1

NOTICE:DONOTusethemasterelectricaldisconnectswitchtostoptheengine.

NOTE:Afterengineshutdown,theSCRsystemwillperformapurgecyclewhichpermitsthesupplymoduletocon-

tinuetorun.Donotshutoffthemasterdisconnectfor70secondsafterkeyoff.

3-39
