3-CONTROLSANDINSTRUMENTS
FORWARDCONTROLS
Ignitionswitch
WARNING
Hazardtobystanders!
Alwayssoundthehornbeforestartingthemachine.Makesuretheworkareaisclearofotherpersons,
domesticanimals,tools,etc.beforeyouoperatethemachine.Neverallowanyoneintheworkarea
duringmachineoperation.
Failuretocomplycouldresultindeathorseriousinjury.
W0304A
Ignitionswitch
Theignitionswitchhasfourpositions:
Accessoryposition:Thisposition
energizesthedrivetraincontroller,
accessoryswitchesandinstrument
cluster.
Enginestop(OFFposition):Turnthekey
toSTOPinordertostoptheengine.After
theenginehasstopped,removethekey.
EngineON(ONposition):Turnthekey
clockwisetoONandcheckthewarning
lamps.Thisisthenormalpositionofthe
ignitionswitchwhentheengineisrunning.
Enginestart(startposition):Turnthe
keycompletelyclockwisetotheSTART
positiontoactuatethestartermotor.After
theenginestarts,releasethekey.The
switchisspringloadedandwillreturn
automaticallytotheONpositionwhen
released.
RAPH12DOZ0132AA1
NOTICE:Afterengineshutdown,theSCRsystemwillperformapurgecyclewhichpermitsthesupplymoduleto
continuetorun.Donotshutoffthemasterdisconnectfor70secondsafterkeyoff.
3-8
